The Doctor Blade More Than Just Cleaning

Typically, impurities on the roll surface originate from fiber bundles in the slurry, filler agglomerates, latex coagulates, resins, dust, metal particles generated by equipment wear, and lubricant contaminants.

During the papermaking process, the generation and accumulation of impurities are inevitable. Therefore, using a doctor blade to remove these impurities to prevent paper defects caused by their accumulation has become a critical step in the papermaking process.

However, it is important to note that while doctor blade wear undoubtedly affects the quality of the paper produced, the improper use of blades and associated equipment can also lead to a range of paper defects.

If the doctor blade fails to effectively remove impurities from the roll surface due to insufficient pressure, blade wear, or uneven contact. These impurities will transfer to or readhere to the paper web, resulting in the formation of dirt spots.

This question is caused by uneven scraping or the accumulation of impurities behind the doctor blade.

Particularly in the press section, when the moisture content is high or the steam pressure from the steam box is excessive, paper fibers tend to adhere to the surface of the bottom roll. The accumulation of these fibers lifts the doctor, resulting in indentations on the paper surface. Once the top roll doctor blade is lifted in this manner, fibers on the blade can easily slip past it and fall onto the paper web, causing holes in the sheet.

Excessive buildup or scratches caused by the doctor blade on the roller surface can not only disrupt the paper web’s run but may even directly damage the paper surface, leading to paper breaks. In addition, vibrations generated by the doctor blade during high speed operation can create water lines or localized wet spots on the paper surface. These areas of compromised strength then become potential sources of paper breaks.

It is essential to regularly inspect the dryer cylinder doctor blade to ensure a tight seal, check for wear, and verify the absence of impurity accumulation caused by other factors. This prevents paper debris from slipping past the blade and adhering to the paper web, thereby effectively avoiding increased paper surface roughness—or even localized friction induced fires.

By controlling and adjusting parameters such as the doctor blade angle, pressure, blade edge profile, and coating fluid viscosity, the volume of coating fluid scraped off, and the amount applied are precisely controlled, thereby regulating the coating thickness.

Impurities that the doctor blade fails to remove compromise the uniformity and smoothness of the coating layer, leading to defects such as coating spots and "orange peel" texture. All of these directly impact the paper's gloss, flatness, and ink absorbency.

The quality of the doctor blade and the accumulation of impurities affect the uniform application of the sizing solution, thereby influencing the paper's water resistance, surface strength, printability, and other properties.

The doctor blade can reduce the moisture content of the paper web by scraping away free water from the roll surface. Particularly at the inlets of the press and dryer sections, doctors assist in the preliminary removal of a portion of the moisture, thereby alleviating the load on subsequent pressing and drying processes and enhancing dewatering and drying efficiency.

Improves Sheet Uniformity—A more uniform moisture distribution facilitates more even drying of the paper sheet, thereby reducing wrinkles and curling.

Enhances Drying Efficiency—The preliminary removal of moisture by doctor blades helps reduce energy consumption during drying and boosts production efficiency.

Increases Paper Strength—

Uniform drying promotes the uniform bonding of cellulose fibers, thereby enhancing the overall strength of the paper.

The doctor blade minimizes surface impurities by cleaning the roll face, thereby facilitating uniform coating and sizing. These actions collectively contribute to enhancing the smoothness of the paper surface.

Precise control of the doctor blade directly determines the quality of the coating layer, enabling the formation of a smooth, uniform, and glossy finish. This, in turn, boosts the paper's gloss level, improves the uniform transfer and absorption of ink, and ultimately enhances the paper's printability.

The use of doctor blades effectively ensures the cleanliness of the roll surface, thereby extending its service life and, consequently:

Reducing Downtime — Minimizing downtime caused by paper defects, sheet breaks, and roll surface malfunctions.

Increasing Machine Speed — Stable sheet runnability allows for higher operating speeds.

Lowering Energy Consumption — Doctor blade optimization enhances dewatering and drying efficiency, thereby reducing energy consumption.

Reducing Reject Rates — Minimizing paper defects and improving paper quality leads to a reduction in reject rates.
