Multi Passage Rotary Joint

Multi passage rotary joint Internally contain two or more completely isolated fluid passages. These passages can simultaneously transmit different media (such as inlet and outlet, inlet and outlet) without interfering with each other. Multi passage rotary joints have complex structures and high processing accuracy requirements, and are commonly used in complex equipment that requires multiple fluid exchanges simultaneously, such as multi-color printing machines and complex hydraulic rotary platforms.

Use Multi Passage

Origin China

Specification Customize

Transport Package By Air or Sea

Trademark SUN HONG

HS Code 84399900

Consult Now

Detail

What is a Multi Passage Rotary Joint?

Multi passage rotary joints are mechanical sealing devices that connect fixed pipelines and rotating components, mainly divided into single circuit, double circuit, and multi-passage types. The shell is made of aluminum alloy material and supported by precision bearings inside, with low friction coefficient and corrosion resistance. The sealing surface and sealing ring are made of wear-resistant materials such as carbon powder and graphite, and the wear condition can be directly observed through appearance, making it easy to maintain and replace. This multi passage rotary joint supports side or rear inlet configuration, suitable for media including water, oil, gas, steam, etc., with a maximum working pressure of 40MPa and a maximum speed of 8000RPM. It can be adapted to 2-26 passages designs and is widely used in fields such as CNC machine tools, hydraulic equipment, printing machinery, etc.
