Sun Hong Carbon Fiber Doctor Blade
Paper Machine Carbon Fiber Doctor Blade
The carbon fiber doctor blade is Sun Hong's best-selling doctor blade. It is manufactured through a lamination process, in which materials (such as individual carbon fiber fabrics or a combination of carbon fiber fabrics and glass fiber fabrics) are bonded together using a special adhesive formulation. Carbon fiber cloth and glass fiber cloth are cured and shaped through special treatments such as impregnation, cutting, and auxiliary materials, and then slitting, cutting, and grinding.
Application of Carbon Fiber Doctor Blade in Paper Machine
Carbon fiber doctor blade is an important equipment in paper production line. The doctor blade holds the blade in a fixed position and oscillates back and forth under constant pressure to remove contaminants and water from the surface of the dryer, such as oscillating on a smooth press roll to remove contaminants and water caused by the paper. Debris from the cracked surface for guide roll cleaning, when used in conjunction with a spray system, the cleaning effect is more significant.
Carbon Fiber Doctor Blade Features
Long service life.
Precise heat treatment.
Excellent cutting longevity.
Wear resistance.
High intensity.
High toughness.
Small thermal deformation.
|
|
|
Carbon Fiber Doctor Blade Classification
SH-2C--Carbon Fiber Doctor Blade
Main applications: for ceramic rolls, drying rolls, hard rubber rolls.
Main features: carton fiber 20%; epoxy glass fiber with better lubrication and anti-wear; temperature resistance: 185℃; bending strength: 600N/m㎡
SH-4C--Carbon Fiber Doctor Blade
Main applications: for ceramic rolls, dryer rolls, hard rubber rolls.
Main features: Carton fiber is 40%; Epo-glass fiber with better lubrication and anti-wear; temperature resistance: 185℃; bending strength: 760N/m㎡
SH-6C--Carbon Fiber Doctor Blade
Main applications: for ceramic rolls, drying rolls, hard rubber rolls.
Main features: carton fiber 60%; made of epoxy glass fiber with good lubrication and anti-wear; temperature resistance: 185℃; bending strength: 790N/m㎡.
SH-100C--Carbon Fiber Doctor Blade
Main applications: for ceramic rolls, drying rolls, hard rubber rolls.
Main features: the blade is made of 100% carton fiber one-time pressing; it has the best lubrication and anti-wear properties; temperature resistance: 185℃; bending strength: 1000N/m㎡.
